Recently, the independently developed JSR6 series 40.5kV gas-insulated metal-enclosed switchgear by Juhonkia Electric has successfully passed the comprehensive type tests conducted by TÜV Rheinland Group of Germany and obtained the authoritative certification certificate. This marks that Juhonkia Electric has reached the international advanced level in product design, manufacturing technology and quality control.
International Authoritative Certification, a Hallmark of Excellent Quality
This certification was based on the IEC 62271 series of international standards, with the product undergoing rigorous type test verification. The expert team of TÜV Rheinland conducted a full range of tests on Juhongkai's JSR6-40.5 series switchgear, including dielectric performance, temperature rise test and short-circuit breaking capacity.
Key technical indicators deliver outstanding performance
In various rigorous tests, Juhonkia switchgear demonstrated exceptional performance:
Reliable Insulation Performance: It successfully passed the 95kV power frequency withstand voltage test and 185kV lightning impulse withstand voltage test, with insulation level fully meeting standard requirements.
Strong Short-Circuit Breaking Capacity: It passed the 25kA/4s short-time withstand current test and 63kA peak withstand current test, verifying the product’s stability under short-circuit faults.
High Internal Arc Protection Rating: It passed the IAC AFLR 25kA internal arc fault test, providing a higher level of safety protection.
Highlights of Innovative Technologies
Intelligent Design: The product adopts vacuum circuit breaker technology and is equipped with a spring operating mechanism, supporting both electric and manual operation with high operational reliability.
Compact Structure: The overall cabinet dimensions are only 460mm (W) × 900mm (D) × 1900mm (H), effectively saving installation space.
High Protection Rating: The enclosure protection rating reaches IP4X and the gas compartment protection rating reaches IP67, making it suitable for various harsh environments.
Rigorous Testing Validates Superior Quality
During the months-long testing period, Juhongkai's products underwent 20,000 mechanical operation tests, 5,000 disconnector operation tests and 2,000 earthing switch operation tests, with all performance indicators remaining stable. This fully demonstrates the reliability and durability of the products.
The temperature rise test showed that when operating continuously at 1.1 times the rated current (630A), the temperature rise of all parts of the product was lower than the standard limit, indicating excellent heat dissipation performance.
Create Greater Value for Customers
Earning the TUV certification this time is not only a recognition of Juhongkai's product quality, but also delivers tangible value to customers:
Enhanced Safety: Backed by an internationally authoritative certification, it ensures greater peace of mind in use.
Improved Reliability: Validated through rigorous testing, it guarantees more stable operation.
Access to International Markets: Equipped with internationally recognized certification qualifications, it facilitates more convenient exports.
Extended Service Life: Boasting excellent design and craftsmanship, it makes the equipment more durable.
About Juhonkia Electric
Zhejiang Juhonkia Electric Co., Ltd. has been committed to the R&D and manufacturing of smart grid equipment, boasting a sound quality management system and a strong technical R&D team. The company's products have been widely applied in fields such as power systems, industrial projects and infrastructure construction.
Juhonkia's four major product categories—including high-voltage switchgear, low-voltage switchgear assemblies, ring main units and outdoor automation equipment—have successfully obtained CE certification, as well as the EAC Certification.
